Bollinger Bands w/Trend Color For ThinkOrSwim

petergluis

Active member
I figured out how to add cloud colors to show uptrends and downtrends.


Ruby:
input price = close;
input displace = 0;
input length = 20;
input Num_Dev_Dn = -2.0;
input Num_Dev_up = 2.0;
input averageType = AverageType.Simple;
input fill= yes;
def sDev = stdev(data = price[-displace], length = length);

plot MidLine = MovingAverage(averageType, data = price[-displace], length = length);
plot LowerBand = MidLine + num_Dev_Dn * sDev;
plot UpperBand = MidLine + num_Dev_Up * sDev;

LowerBand.SetDefaultColor(GetColor(0));
MidLine.SetDefaultColor(GetColor(1));
UpperBand.SetDefaultColor(GetColor(5));
def nan      =   Double.NaN;
def Chg      =   If((UpperBand > UpperBand[1] and LowerBand > LowerBand[1]), 1, If((UpperBand < UpperBand[1] and LowerBand < LowerBand[1]), -1, 0));
def Hold     =   CompoundValue(1, If(Hold[1] == Chg or Chg == 0, Hold[1], If(Chg == 1, 1, -1)), 0);
def LBUp     =   if fill and Hold[0] == 1 then lowerBand else nan;
def UBUp     =   if fill and Hold[0] == 1 then upperband else nan;
def LBDn     =   if fill and Hold[0] == -1 then lowerband else nan;
def UBDn     =   if fill and Hold[0] == -1 then upperband else nan;
DefineGlobalColor("Cloud Up", Color.magenta);
DefineGlobalColor("Cloud Dn", Color.green);
AddCloud(LBUp, UBUp, GlobalColor("Cloud Up"), GlobalColor("Cloud Dn"));
AddCloud(LBDn, UBDn, GlobalColor("Cloud Dn"), GlobalColor("Cloud Up"));

Last edited by a moderator:

Join useThinkScript to post your question to a community of 21,000+ developers and traders.

I add four band colors to show uptrends and downtrends.

Ruby:
input price = close;
input displace = 0;
input length = 20;
input Num_Dev_Dn = -2.0;
input Num_Dev_up = 2.0;
input averageType = AverageType.Simple;
input fill= yes;
def sDev = stdev(data = price[-displace], length = length);

plot MidLine = MovingAverage(averageType, data = price[-displace], length = length);
plot LowerBand = MidLine + num_Dev_Dn * sDev;
plot UpperBand = MidLine + num_Dev_Up * sDev;

LowerBand.SetDefaultColor(GetColor(0));
MidLine.SetDefaultColor(GetColor(1));
UpperBand.SetDefaultColor(GetColor(5));
def a = (UpperBand > UpperBand[1] and Midline > Midline[1]);
def b = (UpperBand < UpperBand[1] and LowerBand < LowerBand[1]);
def c = (UpperBand > UpperBand[1] and Midline > Midline[1]);
def d = (UpperBand < UpperBand[1] and midline < midline[1]);
def e = average(close)>midline;
def f = midline<average(close);
def nan      =   Double.NaN;
def Chg      =   If(a, 1, If(b, -1, 0));
def Hold     =   CompoundValue(1, If(Hold[1] == Chg or Chg == 0, Hold[1], If(Chg == 1, 1, -1)), 0);
def Chg_a      =   If((c or e), 1, If((d or f), -1, 0));
def Hold_a     =   CompoundValue(1, If(Hold[1] == Chg or Chg == 0, Hold[1], If(Chg == 1, 1, -1)), 0);
def LBUp     =   if fill and Hold[0] == 1 then lowerBand else nan;
def UBUp     =   if fill and Hold[0] == 1 then upperband else nan;
def LBDn     =   if fill and Hold[0] == -1 then lowerband else nan;
def UBDn     =   if fill and Hold[0] == -1 then upperband else nan;
def MBUP     =   if fill and Hold[0] == 1 then midline else nan;
def MBDn     =   if fill and Hold[0] == -1 then Midline else nan;

DefineGlobalColor("Cloud Up", Color.red);
DefineGlobalColor("Cloud_Up", Color.yellow);
DefineGlobalColor("Cloud_Dn", Color.cyan);
DefineGlobalColor("Cloud Dn", Color.green);
AddCloud(LBUp, UBUp, GlobalColor("Cloud Up"), GlobalColor("Cloud Dn"));
AddCloud(LBDn, UBDn, GlobalColor("Cloud Dn"), GlobalColor("Cloud Up"));
AddCloud(MBUp, UBUp, GlobalColor("Cloud_Up"), GlobalColor("Cloud_Dn"));
AddCloud(MBDn, UBDn, GlobalColor("Cloud_Dn"), GlobalColor("Cloud_Up"));

Hello, i am looking for Bollinger Bands that will be green when trending up and red when trending down. Thank you in advance:)

Hello, i am looking for Bollinger Bands that will be green when trending up and red when trending down. Thank you in advance:)

This bases the trending up/down based upon comparing the midline to midline[1]. It colors the the lines green/red and adds clouds colored likewise

Ruby:
input price = close;
input displace = 0;
input length = 20;
input Num_Dev_Dn = -2.0;
input Num_Dev_up = 2.0;
input averageType = AverageType.Simple;

def sDev = stdev(data = price[-displace], length = length);

plot MidLine = MovingAverage(averageType, data = price[-displace], length = length);
plot LowerBand = MidLine + num_Dev_Dn * sDev;
plot UpperBand = MidLine + num_Dev_Up * sDev;

LowerBand.assignvalueColor(if midline>=midline[1] then color.green else color.red);
MidLine.assignvalueColor(if midline>=midline[1] then color.green else color.red);
UpperBand.assignvalueColor(if midline>=midline[1] then color.green else color.red);

addcloud(if midline>=midline[1] then upperband else double.nan, midline, color1 = Color.GREEN, color2 = Color.GREEN);
addcloud(if midline<midline[1] then lowerband else double.nan, midline, color1 = Color.red, color2 = Color.red);

@SleepyZ This is great, thank you for sharing. Is it possible to color cloud once the following candle confirms (like once the second candle closes above the midline for uptrend paint cloud and the same thing for a down trend closing below the midline paint cloud?

Last edited:
@SleepyZ This is great, thank you for sharing. Is it possible to color cloud once the following candle confirms (like once the second candle closes above the midline for uptrend paint cloud and the same thing for a down trend closing below the midline paint cloud?

This seems to work as you requested. This will leave areas with no clouds waiting for your condition.

Ruby:
input price = close;
input displace = 0;
input length = 20;
input Num_Dev_Dn = -2.0;
input Num_Dev_up = 2.0;
input averageType = AverageType.SIMPLE;

def sDev = StDev(data = price[-displace], length = length);

plot MidLine = MovingAverage(averageType, data = price[-displace], length = length);
plot LowerBand = MidLine + Num_Dev_Dn * sDev;
plot UpperBand = MidLine + Num_Dev_up * sDev;

LowerBand.AssignValueColor(if MidLine >= MidLine[1] then Color.GREEN else Color.RED);
MidLine.AssignValueColor(if MidLine >= MidLine[1] then Color.GREEN else Color.RED);
UpperBand.AssignValueColor(if MidLine >= MidLine[1] then Color.GREEN else Color.RED);

#Clouds
input showclouds = yes;

def up = if MidLine[1] crosses above MidLine[2] and
         midline > midline[1] and
         close > MidLine
         then 1
         else if up[1] == 1 and MidLine >= MidLine[1]
         then 1
         else if MidLine < MidLine[1]
         then 0
         else up[1];
plot upcloud = up;
#upcloud.setpaintingStrategy(paintingStrategy.VALUES_bELOW);

AddCloud( if showclouds and upcloud
          then UpperBand
          else Double.NaN,
          MidLine, color1 = Color.GREEN, color2 = Color.GREEN);

def dn = if MidLine[1] crosses below MidLine[2] and
         midline < midline[1] and
         close < MidLine
         then 1
         else if dn[1] == 1 and MidLine <= MidLine[1]
         then 1
         else if MidLine > MidLine[1]
         then 0
         else dn[1];

plot dncloud = dn;
#dncloud.setpaintingStrategy(paintingStrategy.VALUES_ABOVE);

AddCloud(if showclouds and dncloud
         then LowerBand
         else Double.NaN,
         MidLine, color1 = Color.RED, color2 = Color.RED);
#
