Hi,

Is there an indicator for TOS which will paint the high and low price for a security for the last 7 days excluding after-hours and pre-market?

And a similar one which will paint the high and low from after-hours and pre-market (1 day before) before the market opens?

Would appreciate if someone could point me towards an indicator like this or if a similar one is available I could try my hand on Think Script.

I believe, knowing the highs and lows for the last 7 days could give us some valuable support and resistance lines.

Thank you!

horserider

horserider

Well-known member
VIP
See if this dos what you want.

Code:
    #High and Lows per day for last 10 days on chart
    #   Put together by Horserider
    input painthigh = 4;#Hint painthigh: 1=dots,2=dashes,3=squares,4=horizontal
def paintingStrategyhigh = if painthigh == 1 then PaintingStrategy.POINTS else if painthigh == 4 then PaintingStrategy.DASHES else if painthigh == 3 then PaintingStrategy.SQUARES else PaintingStrategy.HORIZONTAL;
input paintlow = 4; #Hint paintlow: 1=dots,2=dashes,3=squares,4=horizontal
def paintingStrategylow = if paintlow == 1 then PaintingStrategy.POINTS else if paintlow == 2 then PaintingStrategy.DASHES else if paintlow == 3 then PaintingStrategy.SQUARES else PaintingStrategy.HORIZONTAL;
rec high1 = if GetDay() == GetLastDay() then high(period = AggregationPeriod.DAY) else high1[1];
input colorhigh = 1;#Hint colorhigh: 0=magenta,1=cyan,2=light-red,3=light_green,4=yellow,5=red,6=green,7=light_gray,8=gold,9=white
input colorlow = 1;#Hint colorlow: 0=magenta,1=cyan,2=light-red,3=light_green,4=yellow,5=red,6=green,7=light_gray,8=gold,9=white

plot h1 = high1;


h1.SetPaintingStrategy(paintingStrategyhigh);
h1.SetDefaultColor(GetColor(colorhigh));



rec high2 = if GetDay() == GetLastDay() - 1 then high(period = AggregationPeriod.DAY) else high2[1];
plot h2 = high2;
h2.SetPaintingStrategy(paintingStrategyhigh);
h2.SetDefaultColor(GetColor(colorhigh));
rec high3 = if GetDay() == GetLastDay() - 2 then high(period = AggregationPeriod.DAY) else high3[1];
plot h3 = high3;
h3.SetPaintingStrategy(paintingStrategyhigh);
h3.SetDefaultColor(GetColor(colorhigh));
rec high4 = if GetDay() == GetLastDay() - 3 then high(period = AggregationPeriod.DAY) else high4[1];
plot h4 = high4;
h4.SetPaintingStrategy(paintingStrategyhigh);
h4.SetDefaultColor(GetColor(colorhigh));
rec high5 = if GetDay() == GetLastDay() - 4 then high(period = AggregationPeriod.DAY) else high5[1];
plot h5 = high5;
h5.SetPaintingStrategy(paintingStrategyhigh);
h5.SetDefaultColor(GetColor(colorhigh));
rec high6 = if GetDay() == GetLastDay() - 5 then high(period = AggregationPeriod.DAY) else high6[1];
plot h6 = high6;
h6.SetPaintingStrategy(paintingStrategyhigh);
h6.SetDefaultColor(GetColor(colorhigh));
rec high7 = if GetDay() == GetLastDay() - 6 then high(period = AggregationPeriod.DAY) else high7[1];
plot h7 = high7;
h7.SetPaintingStrategy(paintingStrategyhigh);
h7.SetDefaultColor(GetColor(colorhigh));
rec high8 = if GetDay() == GetLastDay() - 7 then high(period = AggregationPeriod.DAY) else high8[1];
plot h8 = high8;
h8.SetPaintingStrategy(paintingStrategyhigh);
h8.SetDefaultColor(GetColor(colorhigh));
rec high9 = if GetDay() == GetLastDay() - 8 then high(period = AggregationPeriod.DAY) else high9[1];
plot h9 = high9;
h9.SetPaintingStrategy(paintingStrategyhigh);
h9.SetDefaultColor(GetColor(colorhigh));
rec high10 = if GetDay() == GetLastDay() - 9 then high(period = AggregationPeriod.DAY) else high10[1];
plot h10 = high10;
h10.SetPaintingStrategy(paintingStrategyhigh);
h10.SetDefaultColor(GetColor(colorhigh));
rec high11 = if GetDay() == GetLastDay() - 10 then high(period = AggregationPeriod.DAY) else high11[1];
plot h11 = high11;
h11.SetPaintingStrategy(paintingStrategyhigh);
h11.SetDefaultColor(GetColor(colorhigh));
rec high12 = if GetDay() == GetLastDay() - 11 then high(period = AggregationPeriod.DAY) else high12[1];
plot h12 = high12;
h12.SetPaintingStrategy(paintingStrategyhigh);
h12.SetDefaultColor(GetColor(colorhigh));
rec high13 = if GetDay() == GetLastDay() - 12 then high(period = AggregationPeriod.DAY) else high13[1];
plot h13 = high13;
h13.SetPaintingStrategy(paintingStrategyhigh);
h13.SetDefaultColor(GetColor(colorhigh));
rec high14 = if GetDay() == GetLastDay() - 13 then high(period = AggregationPeriod.DAY) else high14[1];
plot h14 = high14;
h14.SetPaintingStrategy(paintingStrategyhigh);
h14.SetDefaultColor(GetColor(colorhigh));
rec high15 = if GetDay() == GetLastDay() - 14 then high(period = AggregationPeriod.DAY) else high15[1];
plot h15 = high15;
h15.SetPaintingStrategy(paintingStrategyhigh);
h15.SetDefaultColor(GetColor(colorhigh));


rec low1 = if GetDay() == GetLastDay() then low(period = AggregationPeriod.DAY) else low1[1];
plot l1 = low1;
l1.SetPaintingStrategy(paintingStrategylow);
l1.SetDefaultColor(GetColor(colorlow));
rec low2 = if GetDay() == GetLastDay() - 1 then low(period = AggregationPeriod.DAY) else low2[1];
plot l2 = low2;
l2.SetPaintingStrategy(paintingStrategylow);
l2.SetDefaultColor(GetColor(colorlow));
rec low3 = if GetDay() == GetLastDay() - 2 then low(period = AggregationPeriod.DAY) else low3[1];
plot l3 = low3;
l3.SetPaintingStrategy(paintingStrategylow);
l3.SetDefaultColor(GetColor(colorlow));
rec low4 = if GetDay() == GetLastDay() - 3 then low(period = AggregationPeriod.DAY) else low4[1];
plot l4 = low4;
l4.SetPaintingStrategy(paintingStrategylow);
l4.SetDefaultColor(GetColor(colorlow));
rec low5 = if GetDay() == GetLastDay() - 4 then low(period = AggregationPeriod.DAY) else low5[1];
plot l5 = low5;
l5.SetPaintingStrategy(paintingStrategylow);
l5.SetDefaultColor(GetColor(colorlow));
rec low6 = if GetDay() == GetLastDay() - 5 then low(period = AggregationPeriod.DAY) else low5[1];
plot l6 = low6;
l6.SetPaintingStrategy(paintingStrategylow);
l6.SetDefaultColor(GetColor(colorlow));
rec low7 = if GetDay() == GetLastDay() - 6 then low(period = AggregationPeriod.DAY) else low7[1];
plot l7 = low7;
l7.SetPaintingStrategy(paintingStrategylow);
l7.SetDefaultColor(GetColor(colorlow));
rec low8 = if GetDay() == GetLastDay() - 7 then low(period = AggregationPeriod.DAY) else low8[1];
plot l8 = low8;
l8.SetPaintingStrategy(paintingStrategylow);
l8.SetDefaultColor(GetColor(colorlow));
rec low9 = if GetDay() == GetLastDay() - 8 then low(period = AggregationPeriod.DAY) else low9[1];
plot l9 = low9;
l9.SetPaintingStrategy(paintingStrategylow);
l9.SetDefaultColor(GetColor(colorlow));
rec low10 = if GetDay() == GetLastDay() - 9 then low(period = AggregationPeriod.DAY) else low10[1];
plot l10 = low10;
l10.SetPaintingStrategy(paintingStrategylow);
l10.SetDefaultColor(GetColor(colorlow));
rec low11 = if GetDay() == GetLastDay() - 10 then low(period = AggregationPeriod.DAY) else low11[1];
plot l11 = low11;
l11.SetPaintingStrategy(paintingStrategylow);
l11.SetDefaultColor(GetColor(colorlow));
rec low12 = if GetDay() == GetLastDay() - 11 then low(period = AggregationPeriod.DAY) else low12[1];
plot l12 = low12;
l12.SetPaintingStrategy(paintingStrategylow);
l12.SetDefaultColor(GetColor(colorlow));
rec low13 = if GetDay() == GetLastDay() - 12 then low(period = AggregationPeriod.DAY) else low13[1];
plot l13 = low13;
l13.SetPaintingStrategy(paintingStrategylow);
l13.SetDefaultColor(GetColor(colorlow));
rec low14 = if GetDay() == GetLastDay() - 13 then low(period = AggregationPeriod.DAY) else low14[1];
plot l14 = low14;
l14.SetPaintingStrategy(paintingStrategylow);
l14.SetDefaultColor(GetColor(colorlow));
rec low15 = if GetDay() == GetLastDay() - 14 then low(period = AggregationPeriod.DAY) else low15[1];
plot l15 = low15;
l15.SetPaintingStrategy(paintingStrategylow);
l15.SetDefaultColor(GetColor(colorlow));

G

ganq

New member
2019 Donor
@horserider Thank you so much, will try it tonight once I get home.

G

ganq

New member
2019 Donor
See if this dos what you want.

Code:
    #High and Lows per day for last 10 days on chart
    #   Put together by Horserider
    input painthigh = 4;#Hint painthigh: 1=dots,2=dashes,3=squares,4=horizontal
def paintingStrategyhigh = if painthigh == 1 then PaintingStrategy.POINTS else if painthigh == 4 then PaintingStrategy.DASHES else if painthigh == 3 then PaintingStrategy.SQUARES else PaintingStrategy.HORIZONTAL;
input paintlow = 4; #Hint paintlow: 1=dots,2=dashes,3=squares,4=horizontal
def paintingStrategylow = if paintlow == 1 then PaintingStrategy.POINTS else if paintlow == 2 then PaintingStrategy.DASHES else if paintlow == 3 then PaintingStrategy.SQUARES else PaintingStrategy.HORIZONTAL;
rec high1 = if GetDay() == GetLastDay() then high(period = AggregationPeriod.DAY) else high1[1];
input colorhigh = 1;#Hint colorhigh: 0=magenta,1=cyan,2=light-red,3=light_green,4=yellow,5=red,6=green,7=light_gray,8=gold,9=white
input colorlow = 1;#Hint colorlow: 0=magenta,1=cyan,2=light-red,3=light_green,4=yellow,5=red,6=green,7=light_gray,8=gold,9=white

plot h1 = high1;


h1.SetPaintingStrategy(paintingStrategyhigh);
h1.SetDefaultColor(GetColor(colorhigh));



rec high2 = if GetDay() == GetLastDay() - 1 then high(period = AggregationPeriod.DAY) else high2[1];
plot h2 = high2;
h2.SetPaintingStrategy(paintingStrategyhigh);
h2.SetDefaultColor(GetColor(colorhigh));
rec high3 = if GetDay() == GetLastDay() - 2 then high(period = AggregationPeriod.DAY) else high3[1];
plot h3 = high3;
h3.SetPaintingStrategy(paintingStrategyhigh);
h3.SetDefaultColor(GetColor(colorhigh));
rec high4 = if GetDay() == GetLastDay() - 3 then high(period = AggregationPeriod.DAY) else high4[1];
plot h4 = high4;
h4.SetPaintingStrategy(paintingStrategyhigh);
h4.SetDefaultColor(GetColor(colorhigh));
rec high5 = if GetDay() == GetLastDay() - 4 then high(period = AggregationPeriod.DAY) else high5[1];
plot h5 = high5;
h5.SetPaintingStrategy(paintingStrategyhigh);
h5.SetDefaultColor(GetColor(colorhigh));
rec high6 = if GetDay() == GetLastDay() - 5 then high(period = AggregationPeriod.DAY) else high6[1];
plot h6 = high6;
h6.SetPaintingStrategy(paintingStrategyhigh);
h6.SetDefaultColor(GetColor(colorhigh));
rec high7 = if GetDay() == GetLastDay() - 6 then high(period = AggregationPeriod.DAY) else high7[1];
plot h7 = high7;
h7.SetPaintingStrategy(paintingStrategyhigh);
h7.SetDefaultColor(GetColor(colorhigh));
rec high8 = if GetDay() == GetLastDay() - 7 then high(period = AggregationPeriod.DAY) else high8[1];
plot h8 = high8;
h8.SetPaintingStrategy(paintingStrategyhigh);
h8.SetDefaultColor(GetColor(colorhigh));
rec high9 = if GetDay() == GetLastDay() - 8 then high(period = AggregationPeriod.DAY) else high9[1];
plot h9 = high9;
h9.SetPaintingStrategy(paintingStrategyhigh);
h9.SetDefaultColor(GetColor(colorhigh));
rec high10 = if GetDay() == GetLastDay() - 9 then high(period = AggregationPeriod.DAY) else high10[1];
plot h10 = high10;
h10.SetPaintingStrategy(paintingStrategyhigh);
h10.SetDefaultColor(GetColor(colorhigh));
rec high11 = if GetDay() == GetLastDay() - 10 then high(period = AggregationPeriod.DAY) else high11[1];
plot h11 = high11;
h11.SetPaintingStrategy(paintingStrategyhigh);
h11.SetDefaultColor(GetColor(colorhigh));
rec high12 = if GetDay() == GetLastDay() - 11 then high(period = AggregationPeriod.DAY) else high12[1];
plot h12 = high12;
h12.SetPaintingStrategy(paintingStrategyhigh);
h12.SetDefaultColor(GetColor(colorhigh));
rec high13 = if GetDay() == GetLastDay() - 12 then high(period = AggregationPeriod.DAY) else high13[1];
plot h13 = high13;
h13.SetPaintingStrategy(paintingStrategyhigh);
h13.SetDefaultColor(GetColor(colorhigh));
rec high14 = if GetDay() == GetLastDay() - 13 then high(period = AggregationPeriod.DAY) else high14[1];
plot h14 = high14;
h14.SetPaintingStrategy(paintingStrategyhigh);
h14.SetDefaultColor(GetColor(colorhigh));
rec high15 = if GetDay() == GetLastDay() - 14 then high(period = AggregationPeriod.DAY) else high15[1];
plot h15 = high15;
h15.SetPaintingStrategy(paintingStrategyhigh);
h15.SetDefaultColor(GetColor(colorhigh));


rec low1 = if GetDay() == GetLastDay() then low(period = AggregationPeriod.DAY) else low1[1];
plot l1 = low1;
l1.SetPaintingStrategy(paintingStrategylow);
l1.SetDefaultColor(GetColor(colorlow));
rec low2 = if GetDay() == GetLastDay() - 1 then low(period = AggregationPeriod.DAY) else low2[1];
plot l2 = low2;
l2.SetPaintingStrategy(paintingStrategylow);
l2.SetDefaultColor(GetColor(colorlow));
rec low3 = if GetDay() == GetLastDay() - 2 then low(period = AggregationPeriod.DAY) else low3[1];
plot l3 = low3;
l3.SetPaintingStrategy(paintingStrategylow);
l3.SetDefaultColor(GetColor(colorlow));
rec low4 = if GetDay() == GetLastDay() - 3 then low(period = AggregationPeriod.DAY) else low4[1];
plot l4 = low4;
l4.SetPaintingStrategy(paintingStrategylow);
l4.SetDefaultColor(GetColor(colorlow));
rec low5 = if GetDay() == GetLastDay() - 4 then low(period = AggregationPeriod.DAY) else low5[1];
plot l5 = low5;
l5.SetPaintingStrategy(paintingStrategylow);
l5.SetDefaultColor(GetColor(colorlow));
rec low6 = if GetDay() == GetLastDay() - 5 then low(period = AggregationPeriod.DAY) else low5[1];
plot l6 = low6;
l6.SetPaintingStrategy(paintingStrategylow);
l6.SetDefaultColor(GetColor(colorlow));
rec low7 = if GetDay() == GetLastDay() - 6 then low(period = AggregationPeriod.DAY) else low7[1];
plot l7 = low7;
l7.SetPaintingStrategy(paintingStrategylow);
l7.SetDefaultColor(GetColor(colorlow));
rec low8 = if GetDay() == GetLastDay() - 7 then low(period = AggregationPeriod.DAY) else low8[1];
plot l8 = low8;
l8.SetPaintingStrategy(paintingStrategylow);
l8.SetDefaultColor(GetColor(colorlow));
rec low9 = if GetDay() == GetLastDay() - 8 then low(period = AggregationPeriod.DAY) else low9[1];
plot l9 = low9;
l9.SetPaintingStrategy(paintingStrategylow);
l9.SetDefaultColor(GetColor(colorlow));
rec low10 = if GetDay() == GetLastDay() - 9 then low(period = AggregationPeriod.DAY) else low10[1];
plot l10 = low10;
l10.SetPaintingStrategy(paintingStrategylow);
l10.SetDefaultColor(GetColor(colorlow));
rec low11 = if GetDay() == GetLastDay() - 10 then low(period = AggregationPeriod.DAY) else low11[1];
plot l11 = low11;
l11.SetPaintingStrategy(paintingStrategylow);
l11.SetDefaultColor(GetColor(colorlow));
rec low12 = if GetDay() == GetLastDay() - 11 then low(period = AggregationPeriod.DAY) else low12[1];
plot l12 = low12;
l12.SetPaintingStrategy(paintingStrategylow);
l12.SetDefaultColor(GetColor(colorlow));
rec low13 = if GetDay() == GetLastDay() - 12 then low(period = AggregationPeriod.DAY) else low13[1];
plot l13 = low13;
l13.SetPaintingStrategy(paintingStrategylow);
l13.SetDefaultColor(GetColor(colorlow));
rec low14 = if GetDay() == GetLastDay() - 13 then low(period = AggregationPeriod.DAY) else low14[1];
plot l14 = low14;
l14.SetPaintingStrategy(paintingStrategylow);
l14.SetDefaultColor(GetColor(colorlow));
rec low15 = if GetDay() == GetLastDay() - 14 then low(period = AggregationPeriod.DAY) else low15[1];
plot l15 = low15;
l15.SetPaintingStrategy(paintingStrategylow);
l15.SetDefaultColor(GetColor(colorlow));
Hi @horserider, I added the above Study to TOS and looked at Apple on the 20 D 5 Min Chart but everything got squished, please advise.

T

tomsk

Well-known member
VIP
Hi @horserider, I added the above Study to TOS and looked at Apple on the 20 D 5 Min Chart but everything got squished, please advise.
The issue you're faced with is that there are too many lines on the chart that are close together
A quick fix is to go to Chart Settings > Price Axis and turn off "Fit studies" and "Fit study markers"

Top
