MCDX indicator For ThinkOrSwim

[MRNAM]

I like to use the MCDX indicator in Trading View,
https://www.tradingview.com/script/u2dIgVpN-M2J-Indicator-MCDX/
it very useful to track the smart money flow, but it is not exist in TOS,



[samer800]

I like to use the MCDX indicator in Trading View,
https://www.tradingview.com/script/u2dIgVpN-M2J-Indicator-MCDX/
it very useful to track the smart money flow, but it is not exist in TOS,

check out the code below.

#// © Mango2Juice
#// MCDX is an indicator based on mutilple relative strength index (RSI) with different period, then classify into 3 categories - Retailer, Hot Money and Banker
#// Green - Retailer
#// Yellow - Hot money
#// Red - Banker
#// the higher and many reds are more preferable
# study("[M2J] Indicator | MCDX", "MCDX")
# Converted by Sam4Cok@Samer800 - 11/2022
declare lower;
input RSIBaseBanker       = 50; # "Banker Base",           minval = 10)
input RSIPeriodBanker     = 50; # "Banker RSI Period",     minval = 10)
input RSIBaseHotMoney     = 30; # "Hot Money RSI Base",    minval = 10)
input RSIPeriodHotMoney   = 40; # "Hot Money RSI Period",  minval = 10)
input SensitivityBanker   = 1.5;# "Sensitivity Banker",    minval = 0.1, step = 0.1)
input SensitivityHotMoney = 0.7;# "Sensitivity Hot Money", minval = 0.1, step = 0.1)

def na = Double.NaN;
#rsi_function(sensitivity, rsiPeriod, rsiBase) =>
script rsi_function {
input sensitivity = 0;
input rsiPeriod = 14;
input rsiBase = 0;
    def rsi = sensitivity * (rsi(Length=rsiPeriod) - rsiBase);
    def nRSI;
    if rsi > 20 {
        nrsi = 20;
    } else {
 if rsi < 0 {
        nrsi = 0;
    } else {
        nrsi = rsi;
}}
   plot result = nrsi;
}

def rsi_Banker   = rsi_function(SensitivityBanker,   RSIPeriodBanker,   RSIBaseBanker);
def rsi_HotMoney = rsi_function(SensitivityHotMoney, RSIPeriodHotMoney, RSIBaseHotMoney);

plot "5" = if(isNaN(close),na,5);#, "5" , color.silver,  2, editable = false)
"5".SetDefaultColor(Color.GRAY);
"5".SetLineWeight(2);
plot "10" = if(isNaN(close),na,10);#, "10", color.fuchsia, 2, editable = false)
"10".SetDefaultColor(Color.MAGENTA);
"10".SetLineWeight(2);
plot "15" = if(isNaN(close),na,15);#, "15", color.silver,  2, editable = false)
"15".SetDefaultColor(Color.GRAY);
"15".SetLineWeight(2);

plot Banker = if(isNaN(close),na,rsi_Banker);#,   "Banker",    #ff0000, 6, plot.style_histogram)
Banker.SetPaintingStrategy(PaintingStrategy.SQUARED_HISTOGRAM);
Banker.SetDefaultColor(CreateColor(255,0,0));

plot HotMoney = if(isNaN(close),na,rsi_HotMoney);#, "Hot Money", #d8c200, 6, plot.style_histogram)
HotMoney.SetPaintingStrategy(PaintingStrategy.SQUARED_HISTOGRAM);
HotMoney.SetDefaultColor(CreateColor(216,194,0));

plot Retailer = if(isNaN(close),na,20);# "Retailer",  #005e07, 6, plot.style_histogram)
Retailer.SetPaintingStrategy(PaintingStrategy.SQUARED_HISTOGRAM);
Retailer.SetDefaultColor(CreateColor(0,94,7));

#--- END Code



[mmm777]

MCDX is an indicator based on mutilple relative strength index (RSI) with different period, then classify into 3 categories - Retailer, Hot Money and Banker

• Green - Retailer
• Yellow - Hot money
• Red - Banker

the higher and many reds are more preferable

the link:https://www.tradingview.com/script/u2dIgVpN-M2J-Indicator-MCDX/



[samer800]

MCDX is an indicator based on mutilple relative strength index (RSI) with different period, then classify into 3 categories - Retailer, Hot Money and Banker

• Green - Retailer
• Yellow - Hot money
• Red - Banker

the higher and many reds are more preferable

the link:https://www.tradingview.com/script/u2dIgVpN-M2J-Indicator-MCDX/

find below

https://usethinkscript.com/threads/mcdx-indicator-for-thinkorswim.12010/#post-111741

#// This source code is subject to the terms of the Mozilla Public License 2.0 at https://mozilla.org/MPL/2.0/
#// © Mango2Juice
#// MCDX is an indicator based on mutilple relative strength index (RSI) with different period, then classify into 3 categories - Retailer, Hot Money and Banker
#// Green - Retailer
#// Yellow - Hot money
#// Red - Banker
#// the higher and many reds are more preferable
#study("[M2J] Indicator | MCDX", "MCDX")
# converted by Sam4Cok@Samer800
declare lower;
input rsiBaseBanker       = 50;        # "Banker Base"
input rsiPeriodBanker     = 50;        # "Banker RSI Period"
input rsiBaseHotMoney     = 30;        # "Hot Money RSI Base"
input rsiPeriodHotMoney   = 40;        # "Hot Money RSI Period"
input SensitivityBanker   = 1.5;       # "Sensitivity Banker"
input SensitivityHotMoney = 0.7;       # "Sensitivity Hot Money"

def na = Double.NaN;
def last = isNaN(close);
#-- Color--
DefineGlobalColor("Retail", CreateColor(0,94,7));
DefineGlobalColor("Hot", CreateColor(216,194,0));
DefineGlobalColor("Banker", CreateColor(255,0,0));
#rsi_function(sensitivity, rsiPeriod, rsiBase) =>
script rsi_function {
input sensitivity = 1.5;
input rsiPeriod = 50;
input rsiBase = 50;
    def rsiValue;
    def rsi_ = rsi(Price=close,Length= rsiPeriod);
    def nRSI = sensitivity * (rsi_ - rsiBase);

    if nRSI > 20 {
        rsiValue = 20;
    } else
    if nRSI < 0 {
        rsiValue = 0;
    } else {
        rsiValue = nRSI;
}
    plot out = rsiValue;
}

def rsi_Banker   = rsi_function(SensitivityBanker,   RSIPeriodBanker,   RSIBaseBanker);
def rsi_HotMoney = rsi_function(SensitivityHotMoney, RSIPeriodHotMoney, RSIBaseHotMoney);

plot "5" = if last then na else 5;
plot "10" = if last then na else 10;
plot "15" = if last then na else 15;
"5".SetDefaultColor(Color.WHITE);
"10".SetDefaultColor(Color.MAGENTA);
"15".SetDefaultColor(Color.WHITE);

plot Banker = rsi_Banker;                    # "Banker"
plot HotMoney = rsi_HotMoney;                # "Hot Money"
plot Retailer = if last then na else 20;     # "Retailer"
Retailer.SetPaintingStrategy(PaintingStrategy.SQUARED_HISTOGRAM);
HotMoney.SetPaintingStrategy(PaintingStrategy.SQUARED_HISTOGRAM);
Banker.SetPaintingStrategy(PaintingStrategy.SQUARED_HISTOGRAM);


Retailer.SetDefaultColor(GlobalColor("Retail"));
HotMoney.SetDefaultColor(GlobalColor("Hot"));
Banker.SetDefaultColor(GlobalColor("Banker"));



#-- END of CODE



[mmm777]

thanks, it is the same.
