Plot horizontal lines based on latest Mark price

[jebersole]

Ok, so I've been messing with this script for about 2 days now and finally decided I needed to ask for some help. I can normally do enough research to find the parts I need and then piece them together. It helps me build my skills in the technology for a nice time investment. However, I'm missing something very very simple that I can't seem to figure out and I would love someone to shed some light on my problem (stupidity) - lack of thinkscript dynamics.

Background: I am a day trader and I closely watch the price of a ticker relative to whole dollars. For example, if a stock has a current price of $423.44, then I will be closely watching its movement between the $423.00 and $424.00 range which is can often be the support and resistance levels. My chart shows 20 days of data in 1m intervals (bars) for the ticker.

Goal: I wanted to write a new script that would plot a horizontal line at the whole value above and below the current mark price. Actually for transparency, i want to plot 3 lines above and 3 lines below, but i can easily do that after doing the first two. So if the last mark price was $423.44, then I would want to draw a horizontal line at both $423.00 and $424.00. But I want to draw (plot) the line only for the current day even though I'm showing 20 days of data. I dont care where the lines would have been relative to other days. I only care about today's lines. So, if the price moves from $423.44 up through $424.00 and lands say at $424.15, then i would like to plot the lines now at $424.00 and $425.00. I want these lines to move with the CURRENT price as it moves up and down.

Along with reading some of the documentation and my research, I found a few golden nuggets to help me achieve some of my goals.

Get the Current Day so I could use If statements to only plot based on the current day
def isCurrentDay = if GetLastDay() == GetDay() then 1 else 0;

Plot the support and resistance lines only if it is the current day
Plot firstResistance = if iscurrentDay then Ceil(423.44) else Double.NaN;
firstResistance.setPaintingStrategy(paintingStrategy.HoRIZONTAL);
firstResistance.SetDefaultColor(Color.Red);
Plot firstSupport = if iscurrentDay then Floor(423.44) else Double.NaN;
firstSupport.setPaintingStrategy(paintingStrategy.HoRIZONTAL);
firstSupport.SetDefaultColor(Color.Green);

Ok, great, now I have my lines that only show up for the current day and they are right where i want them, but unfortunately I have a hard coded value of 423.44 in my examples. The next thing I needed was to find out the current price so my lines would redraw based on that current price. And like WTF, i can't for the life of me get the current price of the current Mark value of the current bar to fill in that hard coded value. I tried using this kind of stuff to get the values...
def isLastBar = !IsNaN(close) and IsNaN(close[-1]);
def LastKnownPrice = If isLastBar Then Ceil(close[0]) else Double.NaN;

Sure, it gets the value of the most recent bar, but since the charting gets painted from the left to the right, i dont know the latest bar value before i need it and obviously if i used the few lines above it will only draw the line if its the last bar. I need to know the current mark/close price back when the chart paints the first bar of that day. I also tried to use CompoundValue, but i dont think i was using it correctly. Does anyone have some advice on how to achieve my task? How do i get the current close/mark price regardless of Aggregation period, etc. Thanks in advance



[Svanoy]

def LastDay = GetDay()==GetLastDay();

def ZeroLevel = if (IsNaN(close) && !IsNaN(close[1])) or IsNaN(close) then ZeroLevel[1] else
                if LastDay then fold c=0 to 1500 while !IsNaN(GetValue(close,-c)) do GetValue(close,-c) else double.nan;

def TA = if (IsNaN(close) && !IsNaN(close[1])) or IsNaN(close) then TA[1] else if !LastDay then 0 else
         if (ZeroLevel - RoundUp(ZeroLevel,0) == 0) then ZeroLevel+1 else RoundUp(ZeroLevel,0);

def TB = if (IsNaN(close) && !IsNaN(close[1])) or IsNaN(close) then TB[1] else if !LastDay then 0 else
         if (ZeroLevel - RoundDown(ZeroLevel,0) == 0) then ZeroLevel-1 else RoundDown(ZeroLevel,0);

def dZL = if IsNaN(close) then dZL[1] else if (ZeroLevel - RoundUp(ZeroLevel,0) == 0) && IsNaN(close[-2000] && LastDay) then
          ZeroLevel else ZeroLevel;

plot ZL =dZL;
ZL.SetPaintingStrategy(PaintingStrategy.HORIZONTAL);
ZL.SetDefaultColor(Color.CYAN);
ZL.SetLineWeight(1);

plot PAC1 = if !TA then Double.NaN else TA;
PAC1.SetPaintingStrategy(PaintingStrategy.HORIZONTAL);
PAC1.SetDefaultColor(Color.LIME);
PAC1.SetLineWeight(1);

plot PAC2 = PAC1+1;
PAC2.SetPaintingStrategy(PaintingStrategy.HORIZONTAL);
PAC2.SetDefaultColor(Color.LIME);
PAC2.SetLineWeight(1);

plot PAC3 = PAC2+1;
PAC3.SetPaintingStrategy(PaintingStrategy.HORIZONTAL);
PAC3.SetDefaultColor(Color.LIME);
PAC3.SetLineWeight(1);

plot PBC1 = if !TB then Double.NaN else TB;
PBC1.SetPaintingStrategy(PaintingStrategy.HORIZONTAL);
PBC1.SetDefaultColor(Color.YELLOW);
PBC1.SetLineWeight(1);

plot PBC2 = PBC1-1;
PBC2.SetPaintingStrategy(PaintingStrategy.HORIZONTAL);
PBC2.SetDefaultColor(Color.YELLOW);
PBC2.SetLineWeight(1);

plot PBC3 = PBC2-1;
PBC3.SetPaintingStrategy(PaintingStrategy.HORIZONTAL);
PBC3.SetDefaultColor(Color.YELLOW);
PBC3.SetLineWeight(1);
