Is it possible to have the date along with the arrow when using a study?

[pymoondra]

Currently, I have a study that displays an arrow when conditions are met:

plot result = if condition then high else Double.NaN;

result.SetPaintingStrategy(PaintingStrategy.ARROW_DOWN);

result.SetLineWeight(4);

result.AssignValueColor(Color.magenta);

However, since I am back testing, I would like the dates to be displayed as well (or instead of the arrows if both can't be displayed)

Is this possible? Currently I have to scroll the mouse to get the date, which is slowing down the process.



[halcyonguy]

Currently, I have a study that displays an arrow when conditions are met:

plot result = if condition then high else Double.NaN;
result.SetPaintingStrategy(PaintingStrategy.ARROW_DOWN);
result.SetLineWeight(4);
result.AssignValueColor(Color.magenta);

However, since I am back testing, I would like the dates to be displayed as well (or instead of the arrows if both can't be displayed)
Is this possible? Currently I have to scroll the mouse to get the date, which is slowing down the process.

this can display a date on a bar, 3 different ways,
bubble (2 versions),
vertical line,
numbers , month above / day below

the font size of the values above/below plot values can't be changed with .SetLineWeight(5).

i moved the arrow up because of the boolean plot number above. i tried to pick factor numbers to get the number, arrow, and bubble stacked and not overlapping most of the time. but some numbers might have to be changed, depending on which output you choose.

replace my 2 averages code with your code that creates the signal.

this took a little longer to do and verify, because you provided partial code. i had to add test code for the signals.

# show_date_on_signal_00

# https://usethinkscript.com/threads/is-it-possible-to-have-the-date-along-with-the-arrow-when-using-a-study.13745/
# Is it possible to have the date along with the arrow when using a study?

def na = double.nan;
def bn = barnumber();
#def lastbar = !isnan(close[0]) and isnan(close[-1]);

#-----------------------------------
#from tos chat - mobius
def data = getYYYYMMDD();
def year = Round(data/10000, 0);
def month = Round((data % 10000) / 100, 0);
def day = (data % 100);
input test_date = no;
addLabel(test_date, "date: " + month + "/" + day + "/" + AsPrice(year), color.white);


#-----------------------------------
# test signals - 2 avg crossing

def price = close;
input ma1_len = 22;
input ma1_type =  AverageType.EXPONENTIAL;
def ma1 = MovingAverage(ma1_type, price, ma1_len);

input ma2_len = 44;
input ma2_type =  AverageType.EXPONENTIAL;
def ma2 = MovingAverage(ma2_type, price, ma2_len);

input show_lines = yes;
plot z1 = if show_lines then ma1 else na;
z1.setdefaultcolor(getcolor(1));
z1.hidebubble();
plot z2 = if show_lines then ma2 else na;
z2.setdefaultcolor(getcolor(2));
z2.hidebubble();
#----------------------------------

def condition = ma1 crosses ma2;

#---------------------------------

input arrow_factor = 0.003;
def dwn = if condition then high*(1+arrow_factor) else Double.NaN;
input show_down_arrow = yes;
input arrow_size = 4;
plot result = dwn;
result.SetPaintingStrategy(PaintingStrategy.ARROW_DOWN);
result.SetLineWeight(arrow_size);
result.AssignValueColor(Color.MAGENTA);

#---------------------------------

# show date on signal bar, in different ways

# bubble
input date_bubble1 = yes;
def vert_factor = 0.001;
#def buby = ( high * (1 + (arrow_size * vert_factor)));
def buby = ( dwn +  (high *((arrow_size * vert_factor))));
addchartbubble(date_bubble1 and dwn, buby, month + "/" + day, color.yellow, yes);

input date_bubble2 = no;
addchartbubble(date_bubble2 and dwn, buby, month + "\n" + day, color.yellow, yes);



# vertical line
input vertical_line_with_date = no;
addverticalline(vertical_line_with_date and dwn,  month + " / " + day, result.takevaluecolor(), curve.SHORT_DASH);
#addverticalline(vertical_line_with_date and dwn,  month + " / " + day +  " / " + AsPrice(year), color.yellow);


# above/below
input date_above_below_candle = yes;
plot dwn_mo = if date_above_below_candle and condition then month else Double.NaN;
dwn_mo.SetPaintingStrategy(PaintingStrategy.values_above);
dwn_mo.AssignValueColor(Color.white);
plot dwn_day = if date_above_below_candle and condition then day else Double.NaN;
dwn_day.SetPaintingStrategy(PaintingStrategy.values_below);
dwn_day.AssignValueColor(Color.white);
#

https://tlc.thinkorswim.com/center/reference/thinkScript/Functions/Look---Feel/AddChartBubble
https://tlc.thinkorswim.com/center/reference/thinkScript/Functions/Look---Feel/AddVerticalLine
https://tlc.thinkorswim.com/center/...aintingStrategy/PaintingStrategy-VALUES-ABOVE



[pymoondra]

this can display a date on a bar, 3 different ways,
bubble (2 versions),
vertical line,
numbers , month above / day below

the font size of the values above/below plot values can't be changed with .SetLineWeight(5).

i moved the arrow up because of the boolean plot number above. i tried to pick factor numbers to get the number, arrow, and bubble stacked and not overlapping most of the time. but some numbers might have to be changed, depending on which output you choose.

replace my 2 averages code with your code that creates the signal.

this took a little longer to do and verify, because you provided partial code. i had to add test code for the signals.

# show_date_on_signal_00

# https://usethinkscript.com/threads/is-it-possible-to-have-the-date-along-with-the-arrow-when-using-a-study.13745/
# Is it possible to have the date along with the arrow when using a study?

def na = double.nan;
def bn = barnumber();
#def lastbar = !isnan(close[0]) and isnan(close[-1]);

#-----------------------------------
#from tos chat - mobius
def data = getYYYYMMDD();
def year = Round(data/10000, 0);
def month = Round((data % 10000) / 100, 0);
def day = (data % 100);
input test_date = no;
addLabel(test_date, "date: " + month + "/" + day + "/" + AsPrice(year), color.white);


#-----------------------------------
# test signals - 2 avg crossing

def price = close;
input ma1_len = 22;
input ma1_type =  AverageType.EXPONENTIAL;
def ma1 = MovingAverage(ma1_type, price, ma1_len);

input ma2_len = 44;
input ma2_type =  AverageType.EXPONENTIAL;
def ma2 = MovingAverage(ma2_type, price, ma2_len);

input show_lines = yes;
plot z1 = if show_lines then ma1 else na;
z1.setdefaultcolor(getcolor(1));
z1.hidebubble();
plot z2 = if show_lines then ma2 else na;
z2.setdefaultcolor(getcolor(2));
z2.hidebubble();
#----------------------------------

def condition = ma1 crosses ma2;

#---------------------------------

input arrow_factor = 0.003;
def dwn = if condition then high*(1+arrow_factor) else Double.NaN;
input show_down_arrow = yes;
input arrow_size = 4;
plot result = dwn;
result.SetPaintingStrategy(PaintingStrategy.ARROW_DOWN);
result.SetLineWeight(arrow_size);
result.AssignValueColor(Color.MAGENTA);

#---------------------------------

# show date on signal bar, in different ways

# bubble
input date_bubble1 = yes;
def vert_factor = 0.001;
#def buby = ( high * (1 + (arrow_size * vert_factor)));
def buby = ( dwn +  (high *((arrow_size * vert_factor))));
addchartbubble(date_bubble1 and dwn, buby, month + "/" + day, color.yellow, yes);

input date_bubble2 = no;
addchartbubble(date_bubble2 and dwn, buby, month + "\n" + day, color.yellow, yes);



# vertical line
input vertical_line_with_date = no;
addverticalline(vertical_line_with_date and dwn,  month + " / " + day, result.takevaluecolor(), curve.SHORT_DASH);
#addverticalline(vertical_line_with_date and dwn,  month + " / " + day +  " / " + AsPrice(year), color.yellow);


# above/below
input date_above_below_candle = yes;
plot dwn_mo = if date_above_below_candle and condition then month else Double.NaN;
dwn_mo.SetPaintingStrategy(PaintingStrategy.values_above);
dwn_mo.AssignValueColor(Color.white);
plot dwn_day = if date_above_below_candle and condition then day else Double.NaN;
dwn_day.SetPaintingStrategy(PaintingStrategy.values_below);
dwn_day.AssignValueColor(Color.white);
#

https://tlc.thinkorswim.com/center/reference/thinkScript/Functions/Look---Feel/AddChartBubble
https://tlc.thinkorswim.com/center/reference/thinkScript/Functions/Look---Feel/AddVerticalLine
https://tlc.thinkorswim.com/center/...aintingStrategy/PaintingStrategy-VALUES-ABOVE

Hi,

Thank you for this. I learned a few things. I am just getting around to play around with this code.

I don't quite understand how dnw works in this case despite using it in my code as well (as result)
Does dwn work as a placeholder for location if our condition results in True?

So in this part of the code:

addchartbubble(date_bubble1 and dwn


date_bubble1 needs to be True
dwn need to just have a non Nan value as that will result in a True as well.

So True and True will equal True.
